Populus-B and Populus-M series are mainly LED outdoor digital signs, one in English size and the other in metric size, which makes it easier for customers to choose.
Pixel Pitch :
6.35mm, 9.525mmLED Type :
SMDModule Dimensions :
304.8x304.8mm (1x1 ft)Active Dimensions :
W: 6/7/8(ft), H: 2/3/4(ft)Brightness :
6000-8000 nitIngress Protection :
IP65Service :
Front / Rear installation, Fron MaintenancePopulus are the most effective dynamic advertising medium and source for sharing community information available. They allow you to capitalize on the local audience passing by your location on a daily basis.
Populus are Graphics and Animation Capable Signs. These outdoor electronic signs feature a variety of pixel pitches depending on the amount of detail desired and various viewing angles to meet different viewing needs.
| TECHNICAL PARAMETER | Populus -B (British) | ||
| Populus-B6 | Populus-B9 | ||
| Physical | Pixel Pitch (mm) | 6.35 | 9.525 |
| Pixel Density (dots) | 24,800 | 11,022 | |
| LED Type | SMD2727 | SMD2727 | |
| Module Dimensions (mm) | 304.8x304.8 | 304.8x304.8 | |
| Module Matrix (dots) | 48x48 | 32x32 | |
| Module Weight (kg) | |||
| Active Dimensions of Display | W: 6/7/8(ft), H: 2/3/4(ft) | ||
| Cabinet Weight (kg) | |||
| Electrical | Scan Mode | 6S | 2S |
| Video Rate (Hz) | 60 | 60 | |
| Refresh rate (Hz) | 1920-3840 | ||
| Color Processing | RGB 65536 levels (3×16bit) | ||
| Data Stored on Module | No | ||
| Input Pvoltage | AC 100~240V 50/60Hz | ||
| Max.consumption (w/m²) | 600 | 600 | |
| Avg. consumption (w/m²) | 200 | 200 | |
| Optical | Brightness (nit) | 6000-10000 | 6000-10000 |
| Contrast Ratio | 8000 : 1 | ||
| Viewing Angle(H/V) | 160° /120° | ||
| Dimming Capability | 256 levels | ||
| Color temperature | 4,500 - 9,000K (Adjustable ) | ||
| Operational | Working Environment | ﹣10℃-+40℃/10%RH-90%RH | |
| Storage Environment | ﹣40℃-+60℃/10%RH-90%RH | ||
| Cooling | Quiet running vent fans | ||
| Ingress Protection | IP66 front / IP55 rear | ||
| LED Lifetime | 100,000 hours | ||
| MTBF | >5,000 hours | ||
| Service | Front / Rear installation, Fron Maintenance | ||
Popsign series has three products which are PA,PB and PD. It has the advantages of fixed size, high brightness, light weight, portable and simple and convenient software operation. The main application is shop, bar, restaurant and other window advertisements, information release, to meet customers' demand for small Led displays.
Learn More
Taxus series is outdoor high-brightness led poster featuring high definition, perfect display ratio of 16:9 with pixel pitch ranging from 1.25mm to 2.6mm, and IP65 high waterproof rating.
Learn More
A waterproof LED outdoor TV created by GOB technology. Crafted with high-quality metal for enduring durability, braving all elements and ensuring an extended lifespan even in extreme weather conditions.
Learn More
Populus-B and Populus-M series are mainly LED outdoor digital signs, one in English size and the other in metric size, which makes it easier for customers to choose.
Learn More
Populus-B and Populus-M series are mainly Led outdoor digital signs, one in English size and the other in metric size, which makes it easier for customers to choose.
Learn More
Fagus series are Led displays around stadiums, with pixel pitch of 6.25mm,8.33mm and 10mm, which can meet various special requirements of stadiums for high brightness, high refresh rate, safety protection and waterproof.
Learn More
